Siemens CS736G1B1, Built-in compact oven with steam function

SKU: CS736G1B1 Category:
  • Oven Assistant with Voice Control: intuitively select the right programme.
  • ecoClean: Cut down on oven cleaning
  • humidClean Plus: softens dirt by vaporising soapy water. Making it easy to wipe away.
  • fullSteam Plus: for fast, healthy steam cooking.
  • Home Connect with Remote Control: unlock the full potential of your smart oven.
Read more...
2 Year Warranty

Got a question? Click here to get in touch.

Features

  • Compact steam oven with 22 heating methods:  conventional top & bottom heating, full width grill, half width grill, coolStart, bottom heat, low temperature cooking, keep warm, plate warming, Conventional heat gentle, steam, reheating with steam, Dough proving, defrost, Hot air grilling, warming, 4D Hot air, Top/bottom heat
  • Temperature range 30 °C – 250 °C
  • 120 °C
  • Cavity volume: 47 litre capacity

Level independent telescopic rails

  • 3 shelf positions
  • Cavity with shelf support rails

Design

  • Touch control With steel trim
  • Cavity inner surface: enamel anthracite

Cleaning

  • hydrolyse program
  • Full glass inner door

Programmes/functions

  • Oven Assistant with Voice Control
  • SE62
  • Electronic oven clock timer
  • Digital temperature display with proposal
  • Actual temperature display
  • Heating-up indicator
  • Drop down oven door, softClose, softOpen
  • cookControl Plus
  • Fast preheat
  • coolStart
  • steam boost – add for 3min intensive steam with a touch of a button.
  • There are different steam intensities selectable: steam level high, steam level middle, steam level low
  • LED light, Light on/off when door opened/closed
  • Tank empty indicator
  • Location of water tank: Outside cavity
  • Integral cooling fan
  • WLAN – Home connect enabled

Accessories

  • 1 x steam container, punched, size M, 1 x steam container, unpunched, size M, 1 x grid, 1 x steam container, punched, size XL, 1 x universal pan

Features

  • Heat reflective glass
  • Control panel lock
  • Automatic safety switch off
  • Residual heat indicator
  • Start button
  • Door contact switch

Technical information

  • Power cord length 150 cm Cable length
  • Nominal voltage: 220 – 240 V
  • Total connected load electric: 3.3 KW
  • Energy efficiency rating (acc. EU Nr. 65/2014): A+
  • Energy consumption per cycle in conventional mode: 0.73 kWh
  • Energy consumption per cycle in fan-forced convection mode: 0.61 kWh
  • Number of cavities: Main cavity
  • Heat source: electrical
  • Cavity volume: 47 litre capacity

Performance/technical information

  • Appliance dimension (hxwxd): 455 mm x 594 mm x 548 mm
  • Niche dimension (hxwxd): 450 mm – 455 mm x 560 mm – 568 mm x 550 mm
  • “For-details-on-installation-and-ventilation requirements – please refer to the installation manual prior to fitting.”
EAN

4242003901441

Colour Name

Black

Features | Benefits

Shorten your cooking time thanks to fast preheat and coolStart. And remote your oven from anywhere with Home Connect.

Country of Origin - Code

GERMANY

Brand Name

Siemens

Width (mm)

594

Height (mm)

455

Depth (mm)

548

Net Weight

33.1

Gross Weight

35.5

Product Family

compact built-in/under oven

Energy Efficiency Class

A+

Control Panel

TFT

Control Panel Material

Glass

Type of Control

Electronic

Type of Control Settings

TFT – touch control;Via app

Construction Type

Built-In

Installation Type

Built-in

Safety Features

Child-proof lock

Type of Light

LED light

Position of Interior Lights

top

Door Color

Black

Door Material

Glass

Door Hinge Type

Drop Down

Appliance Current (A)

16

Appliance Voltage (V)

220-240

Appliance Frequency (Hz)

50; 60

Languages Displayed

Chinese, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hebrew, Italian, Norwegian, Polish, Portuguese, Russian, Slovakian, Spanish, Swedish, Turkish, Ukrainian

Included Accessories

1 x grid, 1 x universal pan, 1 x steam container, punched, size XL, 1 x Steam container, punched, size M, 1 x Steam container, unpunched, size M

Plug Type

Gardy plug w/ earthing

Number of Lights

1

Interior Light

Yes

Lockable Door

No

Depth with Door 90 Degrees

920

Cord Length

150

Min Niche Height

450

Max Niche Height

455

Min Niche Width

560

Max Niche Width

568

Niche Depth

550

Cooker | Oven Control Panel

TFT

Cooker | Oven Timer Control

Electronic

Cooker | Oven Time Options

Start and Stop

Steam Generator Location

Outside cavity

Microwave Cavity Material

Enamelled steel

Cooker | Oven Guides

Grids

Integrated Cleaning System

Catalytic partial, Hydrolytic

Compartment Number of Grids

1

Number of Cooking Programs

3

Cooker | Over Automatic Programs

No

Compartment Probe

No

Compartment Timer

Yes

Microwave Cavity Capacity

47

Water Tank Volume

1

Cooking Usable Volume

47

Automatic Programs

No

Product Group

Combi steam oven

Department Name

Combi Ovens

Division Name

Cooking

Major Department Name

Ovens

Warranty Duration

2

Suggested Hierarchy

306

Compartment Energy Eff Class

0.73

Compartment Energy Eff Index

81.3
