Design:
- Canopy hood
- For installation under an overhead canopy kitchen unit
- Suitable for ducted extraction and recirculation
Core Features:
- Capacitor motor
- 2 x LED spot 2.15W (low volt)
- Colour Temperature: 3500 K
- Light Intensity: 438 lux
- 2 metal grease filter(s).
Comfort Features:
- Slide control operation
- 3 speeds plus intensive
Cleaning Comfort:
- metal grease filter dishwasher-safe
Performance Exhaust:
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in exhaust mode: Speed 1: extraction rate 224 m3/h; noise level 46 dB (A) re1pW Speed 2: extraction rate 365 m3/h; noise level 57 dB (A) re1pW Speed 3: extraction rate 460 m3/h; noise level 63 dB (A) re1pW Intensive 1: extraction rate 604 m3/h; noise level 68 dB (A) re1pW
- Energy Efficiency Class: D (at a range of energy efficiency classes from A+++ to D)
- Average Energy Consumption: 89.4 kWh/year*
- Blower Efficiency Class: D*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: B*
Performance Recirculation:
- For recirculated extraction charcoal filter (accessory) needed
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in recirculation mode with standard recirculation kit (available as optional accessory): Speed 1: extraction rate 150 m3/h; noise level 56 dB (A) re1pW Speed 2: extraction rate 248 m3/h; noise level 67 dB (A) re1pW) Speed 3: extraction rate 302 m3/h ; noise level 71 dB (A) re1pW) Intensive Speed 1: extraction rate346 m3/h; noise level 73 dB (A) re1pW)
Technical Information and Sustainability:
- Consumption data:
- Power rating: 206 W
- Voltage: Nominal voltage: 220 – 240 V
- Sustainability:
- Made in Germany
Planning and Installation Information:
- Dimensions (HxWxD): 215 x 530 x 380 mm
- Built-in dimensions (HxWxD): 215 x 500 x 350 mm
- Electrical cable length 1.3 m
- Diameter pipe Ø 150 mm
Air Flow Boost
604
Appliance Current (A)
10
Appliance Frequency (Hz)
50
Appliance Voltage (V)
220-240
Boost Position Air Extraction
604
Boost Position Output Recirculating
346.0
Brand Name
Neff
Colour Name
Silver
Depth (mm)
380
Gross Weight
7.8
Height (mm)
215
Net Weight
6.8
Width (mm)
530
Cord Length
130
Country of Origin - Code
GERMANY
Diameter of Air Outlet
150
EAN
4242004289821
Energy Efficiency Class
D
Fluid Dynamic Efficiency
13.6
Fluid Dynamic Efficiency Class
D
Grease Filtering Efficiency
87.3
Grease Filtering Efficiency Class
B
Grease Filter Material
Washable aluminium
Installation Type
Built-in
Lighting Efficiency
66.4
Lighting Efficiency Class
A
Max Air Flow
460
Max Niche Width
500
Max Output Air Extraction
460
Max Output Recirculating Air
302
Min Air Flow
224
Min Niche Width
500
Motor Location
Integrated motor in hood body
Niche Depth
350
Noise Level
63
Noise Level Boost Position
68
No Return Air Flow Flap
No
Number of Lights
2
Number of Motors
2
Odor Filter
No
Operating Mode
Convertible
Plug Type
GB plug
Product Group
Hood
Sound Power Max Speed
63
Sound Power Min Speed
46
Type of Control
Mechanical
Type of Control Settings
Mechanical slider
Type of Light
N/A
Typology
Built-in/Built-under
Warranty Duration
2
Construction Type
Built-In
Grease Filter Type
Kassette
Number of Hood Speeds
3
Suggested Hierarchy
313
