Neff D83IDK1S0B, Wall-mounted cooker hood
- Reduced Noise: our optimised motor guarantees a quiet cooking experience.
- Intensive speed setting: increases the extraction rate when the steam gets intense
- Touch Control: an integrated flat surface control panel for smooth operation with a fingerswipe.
- LED Lighting – Clear illumination while you cook.
2 Year Warranty
Design:
- Inclined glass common design
- wall-mounted
- Black glass
- Suitable for ducted extraction and recirculation
- For recirculated extraction recirculating kit (accessory) needed
Core Features:
- Capacitor motor
- 2 x LED lights
- Colour Temperature: 4000 K
- Light Intensity: 127 lux
- 1 metal grease filter(s).
Comfort Features:
- Electronic control via Touch control, backlighted
- 3 speeds plus intensive
- Automatic reset from intensive to normal setting after 5 min
- Saturation indicator for metal and charcoal filter
Cleaning Comfort:
- Large opening angle of the glass plate with locking function for an easy filter accessibility and easy cleaning.
- Easy to clean smooth surfaces and materials.
- metal grease filter dishwasher-safe
Performance Exhaust:
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in exhaust mode: Speed 1: extraction rate 220 m3/h; noise level 46 dB (A) re1pW Speed 2: extraction rate 315 m3/h; noise level 53 dB (A) re1pW Speed 3: extraction rate 430 m3/h; noise level 60 dB (A) re1pW Intensive 1: extraction rate 550 m3/h; noise level 65 dB (A) re1pW
Performance Recirculation:
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in recirculation mode with standard recirculation kit (available as optional accessory): Speed 1: extraction rate 215 m3/h; noise level 51 dB (A) re1pW Speed 2: extraction rate 300 m3/h; noise level 61 dB (A) re1pW) Speed 3: extraction rate 445 m3/h ; noise level 69 dB (A) re1pW) Intensive Speed 1: extraction rate550 m3/h; noise level 72 dB (A) re1pW)
Technical Information and Sustainability:
- Consumption data:
- Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
- Average Energy Consumption: 43.8 kWh/year*
- Blower Efficiency Class: A*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: E*
- Power rating: 223 W
- Voltage: Nominal voltage: 220 – 240 V
Planning and Installation Information:
- Dimensions exhaust air (HxWxD): 690-900 x 790 x 325 mm
- Dimensions recirculating (HxWxD): 720-975 x 790 x 325 mm
- Diameter pipe Ø 150 mm (Ø 150 mm enclosed)
- Electrical cable length 1.5 m
- Back-pressure flap: Yes
EAN
4242004273332
Colour Name
Black
Country of Origin - Code
POLAND
Brand Name
Neff
Width (mm)
790
Height (mm)
325
Depth (mm)
325
Net Weight
11.3
Gross Weight
15.9
Energy Efficiency Class
A
Noise Level
60
Typology
Wall-mounted
Type of Control Settings
touch control
Construction Type
Built-In
Installation Type
Built-in
Type of Light
LED
Appliance Current (A)
4
Appliance Voltage (V)
220-240
Appliance Frequency (Hz)
50
Plug Type
GB plug
Number of Motors
1
Number of Lights
2
Cord Length
150
Operating Mode
Convertible
Chimney Material
Black
Motor Location
Integrated motor in hood body
Fluid Dynamic Efficiency
30.0
Fluid Dynamic Efficiency Class
A
Lighting Efficiency
76.1
Lighting Efficiency Class
A
Grease Filtering Efficiency
55.0
Grease Filtering Efficiency Class
E
Max Air Flow
430
Min Air Flow
220
Air Flow Boost
550
Sound Power Max Speed
60
Sound Power Min Speed
46
Sound Power Boost
65
Noise Level Boost Position
65
Max Output Air Extraction
430
Boost Position Air Extraction
550
Max Output Recirculating Air
445
Boost Position Output Recirculating
550.0
Grease Filter Material
Washable aluminium
Grease Filter Type
Kassette
No Return Air Flow Flap
Yes
Odor Filter
No
Diameter of Air Outlet
150
Height without Chimney
375
Features | Benefits
The Inclined Hood with low-noise motor and Touch Control for an odor- and noisefree kitchen.
Product Group
Hood
Department Name
Wall-Mounted Hoods
Division Name
Cooking
Major Department Name
Hoods
Type of Control
Electronic
Warranty Duration
2
Chimney Color
Black
Suggested Hierarchy
313
Number of Hood Speeds
3
