Neff D94XAF8N0B, Integrated Design Hood
- LED Lighting – Clear illumination while you cook.
2 Year Warranty
Key performance features:
- Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D)
- Extraction rate according to EN 61591 max. 610 m³/h
- Noise max. Normal Level: Noise, max. speed in normal us: 70 dB dB*
Features
- 3 power levels via rotary switch, retractable
- White with LED backlit glass panel
- 2 x LED 2.5W
- Colour Temperature: 3500 K
- Filter cover glass, metal grease filter
- 2 metal grease filter cassettes
- Installation: Cupboard 90 cm
Design
- Adjustable glass visor for additional vapour capture
- Filler strip for an individual depth adjustment in cupboard up to maximum 350 mm.
- Mechanical controls
Performance/technical information
- Suitable for ducted extraction and recirculation
- For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
- Max. extraction rate: 610 m3/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 70 dB(A) re 1 pW
- Power rating: 255 W
- Light Intensity: 76 lux
- Electrical cable length 1.5 m
- Diameter pipe Ø 150 mm (Ø 150 mm enclosed)
- Dimensions (HxWxD): 356 x 894 x 310 mm
- Built-in dimensions (HxWxD): 356 x 862 x 310-350 mm
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: C*
- Average Energy Consumption: 61 kWh/year*
Optional accessories
- Recirculating kit Z51IBU0X0
Air Flow Boost
0.0
Appliance Frequency (Hz)
50; 60
Appliance Voltage (V)
220-240
Approval Certificates
CE
Brand Name
Neff
Chimney Material
Stainless steel
Colour Name
Stainless Steel
Construction Type
Built-In
Depth (mm)
310
Gross Weight
19.4
Net Weight
14.1
Width (mm)
894
Cord Length
150
Country of Origin - Code
ITALY
Department Name
Integrated Hoods
Diameter of Air Outlet
150
Division Name
Cooking
EAN
4242004243632
Energy Efficiency Class
B
Features | Benefits
Our invisible integrated design hood – perfectly integrated with extra storage for easy access items, such as spices and herbs.
Fluid Dynamic Efficiency
26.7
Fluid Dynamic Efficiency Class
B
Grease Filtering Efficiency
75.1
Grease Filtering Efficiency Class
C
Grease Filter Material
Washable aluminium
Grease Filter Type
Kassette
Height without Chimney
60
Installation Type
Built-in
Lighting Efficiency
68.1
Lighting Efficiency Class
A
Major Department Name
Hoods
Max Air Flow
610
Max Niche Width
862
Max Output Air Extraction
610
Max Output Recirculating Air
585
Min Air Flow
230
Min Niche Width
862
Motor Location
Integrated motor in hood body
Niche Depth
310
Noise Level
70
No Return Air Flow Flap
Yes
Number of Lights
2
Number of Motors
1
Odor Filter
No
Operating Mode
Convertible
Product Group
Hood
Sound Power Max Speed
70
Sound Power Min Speed
49
Type of Control
Mechanical
Type of Control Settings
None, rotary switch, retractable
Type of Light
LED
Typology
Built-in/Built-under
Warranty Duration
2
Warranty Type
YR
Supplier SKU
D94XAF8N0B
Suggested Hierarchy
313
Number of Hood Speeds
3
