Bosch DFS097A51B, Telescopic cooker hood
- EcoSilence Drive™: the powerful, energy-saving drive for hoods.
- High extraction rate - for continuously clean air in the kitchen.
- Intensive Setting: the powerful way to beat intense steam during cooking.
- Enjoy the benefits of a cleaner and healthier kitchen, free from excessive grease and unwanted odors.
- LED Illumination: The energy-saving lighting provides bright and clear lighting for the hob area.
2 Year Warranty
Features
- Electronic control via Soft touch button control
- 3 power levels & intensive setting
- 3 x 1,5W LED
- SilentPowerDrive
- Automatic intensive revert (6mins)
- Automatic after running (Automatic after running (10 min))
- 3 removable metal grease filter cassettes
Design
- 90 cm wide
- Silver metallic lacquer
- Handle strip specification: stainless steel with logo
- Steel filter cover
Performance
- Suitable for ducted or recirculating operation
- For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
- Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
- Extraction rate according to EN 61591 max. 729 m³/h
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 397m³/h
- Intensive 729 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 53 dB(A) re 1 pW
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use: 53dB(A) re 1 pW
- Intensive: 69 dB(A) re 1 pW
- With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches:
- Extraction rate in recirculation mode:
- Max. normal use: 358m³/h
- Intensive: 628m³/h
- Noise level in recirculation mode:
- Max. normal use: 60dB(A) re 1 pW
- Intensive: 71 dB(A) re 1 pW
- Colour Temperature: 3500 K
- Light Intensity: 355 lux
- Power rating: 146 W
- Average Energy Consumption: 38.1 kWh/year*
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: B*
Planning and installation information
- Installation system: Telescopic comfort installat.
- Dimensions (HxWxD): 426 x 898 x 290 mm
- Built-in dimensions (HxWxD): 385 x 524 x 290 mm
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Electrical cable length 1.75 m
EAN
4242005232109
Features | Benefits
Telescopic cooker hoods extend when in use and slide neatly away when not in operation.
Country of Origin - Code
GERMANY
Brand Name
Bosch
Width (mm)
898
Depth (mm)
290
Net Weight
12.4
Gross Weight
15.3
Energy Efficiency Class
A
Noise Level
53
Type of Control Settings
Button
Construction Type
Built-In
Installation Type
Built-in
Type of Light
LED
Appliance Current (A)
10
Appliance Voltage (V)
220-240
Appliance Frequency (Hz)
50; 60
Approval Certificates
CE, E17D UKCA marking, VDE
Plug Type
GB plug
Number of Motors
2
Number of Lights
3
Cord Length
175
Min Niche Width
524
Max Niche Width
524
Niche Depth
290
Operating Mode
Convertible
Motor Location
Integrated motor in hood body
Fluid Dynamic Efficiency
28.0
Fluid Dynamic Efficiency Class
B
Lighting Efficiency
65.7
Lighting Efficiency Class
A
Grease Filtering Efficiency
88.3
Grease Filtering Efficiency Class
B
Max Air Flow
397
Min Air Flow
210
Air Flow Boost
729
Sound Power Max Speed
53
Sound Power Min Speed
41
Sound Power Boost
69
Noise Level Boost Position
69
Max Output Air Extraction
397
Boost Position Air Extraction
729
Max Output Recirculating Air
358
Boost Position Output Recirculating
628
Grease Filter Material
Washable stainless steel
No Return Air Flow Flap
Yes
Odor Filter
No
Diameter of Air Outlet
0
Colour Name
Silver metallic
Grease Filter Type
Kassette
Product Group
Hood
Department Name
Telescopic Hoods
Division Name
Cooking
Major Department Name
Hoods
Height (mm)
426
Type of Control
Electronic
Typology
Pull-out
Warranty Duration
2
Suggested Hierarchy
313
