Design:
- Box design
- wall-mounted
- Suitable for ducted or recirculating operation
Core Features:
- Capacitor motor
- 2 x LED 1.5W
- Colour Temperature: 3500 K
- Light Intensity: 293 lux
- 2 metal grease filter(s).
Comfort Features:
- Push button control for extractor speeds and light
- 3 power levels
Cleaning Comfort:
- Easy to clean smooth surfaces and materials.
- Removable metal grease filters dishwasher-safe
- Coated surfaces for less fingerprint sensitivity
Exhaust Mode:
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in exhaust mode:
- Speed 1:Â extraction rate 361 m3/h; noise level 57 dB(A) re1pW
- Speed 2: extraction rate 469 m3/h; noise level 63 dB(A) re1pWÂ
- Speed 3: extraction rate 594 m3/h; noise level 67 dB (A) re1pW
- Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D)
- Average Energy Consumption: 72 kWh/year*
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: B*
Recirculation Mode:
- For recirculation operation Long-life Clean Air recirculation kit (accessory) needed.
- The Long-life Clean Air odour filter absorbs intense odours, such as fish, as well as pollen. The lifetime can be extended up to 4 times by refreshing the filter in the oven
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in recirculation mode with Long-life Clean Air recirculation kit (available as optional accessory):
- Speed 1: extraction rate 360 m3/h; noise level 60 dB(A) re1pW
- Speed 2: extraction rate 477 m3/h; noise level 67 dB(A) re1pW
- Speed 3: extraction rate 569 m3/h; noise level 71 dB (A) re1pW
Technical Information and Sustainability:
- Consumption data:
- Power rating: 200 W
- Voltage: Nominal voltage: 220 – 240 V
- Sustainability:
- Made in Germany
- Available Long-life Clean Air odour filter with extended lifetime up to 4 times
Planning and Installation Information:
- Reduced assembly effort thanks to the easy installation method
- Dimensions exhaust air (HxWxD): 635-895 x 598 x 500 mm
- Dimensions recirculating (HxWxD): 803-1080 x 598 x 500 mm
- Diameter pipe Ø 150 mm
- Electrical cable length 1.3 m
Appliance Frequency (Hz)
50; 60
Appliance Voltage (V)
220-240
Brand Name
Bosch
Chimney Color
Stainless Steel
Colour Name
Stainless Steel
Depth (mm)
500
Gross Weight
17.4
Height (mm)
60
Net Weight
12
Width (mm)
598
Cord Length
130
Country of Origin - Code
GERMANY
Diameter of Air Outlet
150
EAN
4242005530373
Energy Efficiency Class
B
Fluid Dynamic Efficiency
23.6
Fluid Dynamic Efficiency Class
B
Grease Filtering Efficiency
89.0
Grease Filtering Efficiency Class
B
Grease Filter Material
Washable stainless steel
Installation Type
Built-in
Lighting Efficiency
47.3
Lighting Efficiency Class
A
Max Air Flow
594
Max Output Air Extraction
594
Max Output Recirculating Air
569
Min Air Flow
361
Motor Location
Integrated motor in hood chimney
Noise Level
67
No Return Air Flow Flap
No
Number of Lights
2
Number of Motors
1
Odor Filter
No
Operating Mode
Convertible
Plug Type
GB plug
Product Group
Hood
Sound Power Max Speed
67
Sound Power Min Speed
57
Type of Control
Mechanical
Type of Control Settings
Button
Type of Light
LED
Typology
Wall-mounted
Warranty Duration
2
Construction Type
Built-In
Grease Filter Type
Kassette
Number of Hood Speeds
3
Suggested Hierarchy
313
