Bosch HQA534BW3B, Built-in oven with added steam function
- Energy Efficiency Class A+: thanks to improvement of the oven construction you can save energy while cooking.
- Added steam function: by adding steam, baked food turn out crispy on the outside and fluffy on the inside.
- Hotair Steam: heat and humidity are distributed equally within the oven interior so food turns out crispy on the outside and juicy on the inside.
- 3D Hotair: even heat distribution for perfect results on up to three levels.
- EcoClean Direct: less cleaning effort thanks to a special coating of the rear wall that automatically absorbs grime.
2 Year Warranty
Features
- Oven with 8 heating methods: 3D Hotair, conventional top and bottom heat, Hotair grilling, full width variable grill, pizza function, bottom heat, Hotair gentle, hot air and steam combined
- Temperature range 50 °C – 275 °C
- Cavity volume: 71 litre capacity
Level independent telescopic rails
- 5 shelf positions
- Available as an additional accessory
Design
- Rotary dial, Retractable control dials, round With steel trim
- Cavity inner surface: enamel anthracite
- Extra large capacity oven
Cleaning
- CleanCoating
- Full glass inner door
Programmes/functions
- LED-Display Control (Red)
- Electronic clock timer
- Heating-up indicator
- Automatic start
- Straight bar handle
- Fast pre-heating function
- Interior halogen light
- Water bowl with a volume of 250 ml
- Integral cooling fan
Accessories
- 2 x combination grid, 1 x universal pan
Features
- Maximum window temperature 40° C
- Triple glazed door glazed CoolTouch door
- Control panel lock
Technical information
- 120 cm Cable length
- Nominal voltage: 220 – 240 V
- Total connected load electric: 2.8 KW
- Energy efficiency rating (acc. EU Nr. 65/2014): A+
- Energy consumption per cycle in conventional mode: 0.94 kWh
- Energy consumption per cycle in fan-forced convection mode: 0.69 kWh
- Number of cavities: Main cavity
- Heat source: electrical
- Cavity volume: 71 litre capacity
Performance/technical information
- Appliance dimension (hxwxd): 595 mm x 594 mm x 548 mm
- Niche dimension (hxwxd): 585 mm – 595 mm x 560 mm – 568 mm x 550 mm
- “For-details-on-installation-and-ventilation requirements – please refer to the installation manual prior to fitting.”
- We recommend you to choose complementary products within SER4, in order to assure an optimal design combination of your Built-In appliances.
Appliance Current (A)
13
Appliance Frequency (Hz)
50; 60
Control Panel
Fascia printing
Appliance Voltage (V)
220-240
Brand Name
Bosch
Colour Name
white
Construction Type
Built-In
Depth (mm)
548
Gross Weight
36
Height (mm)
595
Net Weight
33.9
Width (mm)
594
Control Panel Material
Glass
Compartment Number of Grids
1
Cooker | Oven Control Panel
Fascia printing
Cooker | Oven Guides
Grids
Cooker | Oven Time Options
Start and Stop
Cooker | Oven Timer Control
Electronic
Cooker | Over Automatic Programs
No
Cooking Methods
Bottom heat, Conventional heat, Full width grill, Hot Air, Hotair gentle, Hot air grilling, Pizza setting
Cooking Usable Volume
71
Cord Length
120
Country of Origin - Code
SPAIN
Door Color
White
Door Material
Glass
Door Opening Type
Drop Down
EAN
4242005465583
Energy Efficiency Class
A+
Energy Input
Electric
Energy Type
Electricity
Features | Benefits
Perfect results: Hotair Steam for delicious baking results.
Automatic Programs
No
Compartment Interior Light
Yes
Compartment Motorized Spit
No
Compartment Probe
No
Compartment Timer
Yes
Integrated Controls
No
Interior Light
Yes
Lockable Door
No
Included Accessories
2 x combination grid, 1 x universal pan
Installation Type
Built-in
Max Niche Height
595
Max Niche Width
568
Microwave Cavity Capacity
71
Microwave Cavity Material
Enamelled steel
Min Niche Height
585
Min Niche Width
560
Niche Depth
550
Number of Cooking Compartments
1
Number of Cooking Programs
5
Number of Lights
1
Plug Type
no plug (electrical connection by electrician)
Position of Interior Lights
top
Product Family
built-in/under single oven
Product Group
Oven
Safety Features
Child-proof lock
Type of Control
Mechanical
Type of Control Settings
Rotary control
Type of Light
Round halogen light
Water Tank Volume
0.2
Department Name
Combi Ovens
Division Name
Cooking
Major Department Name
Ovens
Depth with Door 90 Degrees
1040
Warranty Duration
2
Suggested Hierarchy
306
Door Hinge Type
Drop Down
Compartment Energy Eff Class
0.94
Compartment Energy Eff Index
81.2
