Neff I88WMM1S7B, Downdraft hood
- Guided Air Technology – Equally powerful steam extraction all over the cooktop regardless of the pans’ or pots’ location
- Glass Panel with Illumination – 25 million colour options for inspiring illumination of your cooktop
- Easy Access Filter – A simple push of a button is enough to remove the easy access filter for a good wash in the dishwasher
- High Extraction Rate – ensures a clear view while cooking thanks to an efficient motor technology
- Cooktop-based Hood Control – Adjust your hood´s extraction level and lighting.
2 Year Warranty
Connectivity
- Remote Monitoring and Control for connected home appliances and operation via smartphone or tablet (only in countries where Home Connect service is available)
- The Home Connect functionality can be extended by integrating numerous applications from external cooperation partners (partnerships)
- Voice Control enabled via popular voice assistants (only in countries where this service is available)
- Interval function: available via Home Connect
- Silence function: available via Home Connect
Variant
- 80 cm wide
- Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
- Extraction rate exhaust air according to EN 61591:
- max. normal use 501 m³/h, intensive 775 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 62 dB(A) re 1 pW
Features
- Fully automatic hood
- Hob-Hood control (with Wi-Fi enabled hob)
- climateControl Sensor
- Additional functions: Ambient light RGB
- 3 power levels and 2 intensive settings
- Touch control
- The standard functions are located on the right-hand user interface
- Efficient BLDC technology
- Automatic intensive revert (6mins)
- Automatic after running (Automatic after running (10 minutes))
- 2 metal grease filter cassettes
- Saturation indicator for metal and charcoal filter
- The filter service button automatically lifts filters into service position for easy removal
Design
- Extendable clear glass panel with edge lighting
- The glass panel can be easily removed and cleaned
- Installation: integrated
- Suitable for installation in an island or Semi-island kitchen solution
Performance
- Suitable for ducted extraction and recirculation
- For recirculated extraction Clean Air Plus recirculation kit (accessory) needed
- Maximum extraction rate exhaust air 501 m³/h according to EN 61591
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 501m³/h
- Intensive 775 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use: 62dB(A) re 1 pW
- Intensive: 70 dB(A) re 1 pW
- Noise max. Normal Level: Noise, max. speed in normal us: 62 dB dB*
- With the Clean Air Plus recirculation kit (available as optional accessory) your appliances reaches:
- Extraction rate in recirculation mode:
- Max. normal use: 416m³/h
- Intensive: 525m³/h
- Noise level in recirculation mode:
- Max. normal use: 65dB(A) re 1 pW
- Intensive: 70 dB(A) re 1 pW
- Average Energy Consumption: 36.9 kWh/year*
- Blower Efficiency Class: A*
- Lighting Efficiency Class: -*
- Grease Filtering Efficiency Class: B*
- Power rating: 300 W
Planning and installation information
- Not suitable for combination with gas hobs
- Extension height 250 mm
- Dimensions (HxWxD): 709 x 802 x 140 mm
- Built-in dimensions (HxWxD): 703 x 781 x 123 mm
- Extractor hose 150 mm
- Electrical cable length 1.3 m
- Please reference the built-in dimensions provided in the installation drawings
EAN
4242004252306
Country of Origin - Code
GERMANY
Brand Name
Neff
Width (mm)
802
Depth (mm)
140
Net Weight
38.9
Gross Weight
48.1
Energy Efficiency Class
A
Noise Level
62
Typology
Downdraft
Type of Control
Electronic
Type of Control Settings
Touch control;Via app
Construction Type
Built-In
Installation Type
Built-in
Appliance Current (A)
10
Appliance Voltage (V)
220-240
Appliance Frequency (Hz)
60; 50
Plug Type
GB plug
Number of Motors
1
Cord Length
130
Min Niche Width
781
Max Niche Width
781
Niche Depth
123
Operating Mode
Convertible
Motor Location
Integrated motor in hood body
Fluid Dynamic Efficiency
29.6
Fluid Dynamic Efficiency Class
A
Lighting Efficiency Class
–
Grease Filtering Efficiency
90.7
Grease Filtering Efficiency Class
B
Max Air Flow
501
Min Air Flow
223
Air Flow Boost
775
Sound Power Max Speed
62
Sound Power Min Speed
39
Sound Power Boost
70
Noise Level Boost Position
70
Max Output Air Extraction
501
Boost Position Air Extraction
775
Max Output Recirculating Air
416
Boost Position Output Recirculating
525
Grease Filter Material
Washable stainless steel
Grease Filter Type
Kassette
No Return Air Flow Flap
No
Odor Filter
No
Diameter of Air Outlet
150
Product Group
Hood
Department Name
Downdraft Hoods
Division Name
Cooking
Major Department Name
Hoods
Colour Name
Black
Height (mm)
709
Warranty Duration
2
Type of Light
N/A
Suggested Hierarchy
313
Number of Hood Speeds
4
