Siemens LI94MA531B, Telescopic cooker hood
- iQdrive motor - The quiet, high-performance motor ensures efficient removal of odours and steam.
- Illuminate your cooking space with LED lights for optimal visibility and ambience setting.
- Fast-acting extraction for sudden bursts of steam - Intensive Setting
2 Year Warranty
Features
- Soft touch button control with Electronic display
- 3 x power levels plus intensive setting
- 3 x 1,5W LED
- iQdrive Motor
- Automatic intensive revert (6mins)
- Automatic after running (Automatic after running (10 minutes))
- 3 x metal grease filter cassettes – dishwasher safe
Design
- 90 cm wide
- Silver metallic lacquer
- Handle strip specification: stainless steel with logo
- Filter cover stainless steel, perforated and dishwasher safe
Performance
- Suitable for ducted and re-circulating operation
- For recirculated extraction recirculating kit (accessory) needed
- Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 266m³/h
- Intensive 412 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 63 dB(A) re 1 pW
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use: 63dB(A) re 1 pW
- Intensive: 70 dB(A) re 1 pW
- Colour Temperature: 3500 K
- Light Intensity: 355 lux
- Power rating: 76 W
- Average Energy Consumption: 22.2 kWh/year*
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: C*
Planning and installation information
- Dimensions (HxWxD): 203 x 898 x 290 mm
- Built-in dimensions (HxWxD): 162 x 526 x 290 mm
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Electrical cable length 1.75 m
EAN
4242003880234
Features | Benefits
For clean lines the powerful telescopic cooker hood disappears into an upper cabinet, perfect for modern kitchens.
Country of Origin - Code
GERMANY
Brand Name
Siemens
Width (mm)
898
Depth (mm)
290
Net Weight
10.4
Gross Weight
12.8
Energy Efficiency Class
A
Noise Level
63
Type of Control Settings
Button
Construction Type
Built-In
Installation Type
Built-in
Type of Light
LED
Appliance Current (A)
10
Appliance Voltage (V)
220-240
Appliance Frequency (Hz)
50; 60
Approval Certificates
CE, E17D UKCA marking, VDE
Plug Type
GB plug
Number of Motors
1
Number of Lights
3
Cord Length
175
Min Niche Width
526
Max Niche Width
526
Niche Depth
290
Operating Mode
Convertible
Motor Location
Integrated motor in hood body
Fluid Dynamic Efficiency
23.7
Fluid Dynamic Efficiency Class
B
Lighting Efficiency
65.7
Lighting Efficiency Class
A
Grease Filtering Efficiency
81.8
Grease Filtering Efficiency Class
C
Max Air Flow
266
Min Air Flow
164
Air Flow Boost
412
Sound Power Max Speed
63
Sound Power Min Speed
50
Sound Power Boost
70
Noise Level Boost Position
70
Max Output Air Extraction
266
Boost Position Air Extraction
412
Max Output Recirculating Air
263
Boost Position Output Recirculating
353
Grease Filter Material
Washable aluminium
No Return Air Flow Flap
No
Odor Filter
No
Diameter of Air Outlet
0
Colour Name
Silver metallic
Grease Filter Type
Kassette
Product Group
Hood
Height (mm)
203
Type of Control
Electronic
Typology
Pull-out
Department Name
Telescopic Hoods
Division Name
Cooking
Major Department Name
Hoods
Warranty Duration
2
Suggested Hierarchy
313
