Neff D49ED22N1B, Telescopic cooker hood
- Efficient Drive Motor – Quiet and energy-efficient hood motor for a calmer kitchen.
- Intensive speed setting: increases the extraction rate when the steam gets intense
- LED Lighting – Clear illumination while you cook.
- Automatic After-running – ventilation continues for several minutes after you turn it off
2 Year Warranty
Features
- Electronic controls via Soft touch control
- 3 speeds plus intensive
- 3 x 1,5W LED
- Efficient BLDC technology
- Automatic intensive revert (6mins)
- Automatic after running (Automatic after running (10 minutes))
- 3 metal grease filter cassettes
Design
- 90 cm wide
- Silver metallic grey
- Handle strip specification: stainless steel with logo
- Filter cover stainless steel, perforated and dishwasher safe
Performance
- Suitable for ducted extraction and recirculation
- For recirculated extraction recirculating kit (accessory) needed
- Energy Efficiency Class: A (at a range of energy efficiency classes from A+++ to D)
- Extraction rate according to EN 61591 ø 15 cm:
- max. Normal use 266m³/h
- Intensive 412 m³/h
- Noise level according to EN 60704-3 and EN 60704-2-13 at max. normal use exhaust air: 63 dB(A) re 1 pW
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
- Max. normal use: 63dB(A) re 1 pW
- Intensive: 70 dB(A) re 1 pW
- Colour Temperature: 3500 K
- Light Intensity: 355 lux
- Average Energy Consumption: 22.2 kWh/year*
- Power rating: 76 W
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: C*
Planning and installation information
- Dimensions (HxWxD): 203 x 898 x 290 mm
- Built-in dimensions (HxWxD): 162 x 526 x 290 mm
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Electrical cable length 1.75 m
EAN
4242004251163
Features | Benefits
Telescopic hood: designed to provide powerful extraction without impacting on your kitchen space or design. These hoods pull out from underneath a cabinet when required for a streamlined kitchen.
Country of Origin - Code
GERMANY
Brand Name
Neff
Width (mm)
898
Depth (mm)
290
Net Weight
10.2
Gross Weight
12.5
Energy Efficiency Class
A
Noise Level
63
Type of Control Settings
Button
Construction Type
Built-In
Installation Type
Built-in
Type of Light
LED
Appliance Current (A)
10
Appliance Voltage (V)
220-240
Appliance Frequency (Hz)
50; 60
Approval Certificates
CE, E17D UKCA marking, VDE
Plug Type
GB plug
Number of Motors
1
Number of Lights
3
Cord Length
175
Min Niche Width
526
Max Niche Width
526
Niche Depth
290
Operating Mode
Convertible
Motor Location
Integrated motor in hood body
Fluid Dynamic Efficiency
23.7
Fluid Dynamic Efficiency Class
B
Lighting Efficiency
65.7
Lighting Efficiency Class
A
Grease Filtering Efficiency
81.8
Grease Filtering Efficiency Class
C
Max Air Flow
266
Min Air Flow
164
Air Flow Boost
412
Sound Power Max Speed
63
Sound Power Min Speed
50
Sound Power Boost
70
Noise Level Boost Position
70
Max Output Air Extraction
266
Boost Position Air Extraction
412
Max Output Recirculating Air
263
Boost Position Output Recirculating
353
Grease Filter Material
Washable aluminium
No Return Air Flow Flap
No
Odor Filter
No
Diameter of Air Outlet
0
Colour Name
Silver
Grease Filter Type
Kassette
Product Group
Hood
Department Name
Telescopic Hoods
Division Name
Cooking
Major Department Name
Hoods
Height (mm)
203
Type of Control
Electronic
Typology
Pull-out
Warranty Duration
2
Suggested Hierarchy
313
Number of Hood Speeds
3
