Design:
- Installation in a wall cupboard
- Flush-fitted installation for a seamless integration in wall cupboards.
- Glass panel: clear glass
- Enlarged storage space: max. 10 kg capacity on each hood side
- Suitable for ducted extraction and recirculation
Core Features:
- Capacitor energy efficient
- 2 x LED 1.5W
- Colour Temperature: 3500 K
- Light Intensity: 316 lux
- 2 metal grease filter(s).
Comfort Features:
- Adjustable glass visor for additional vapour capture
- Cupboard protection: additional side and rear protection against vapour
- Push button control operation for extractor speeds and light
- 3 power levels
Cleaning Comfort:
- Easy to clean smooth surfaces and materials.
- metal grease filter dishwasher-safe
- Coated surfaces for less fingerprint sensitivity
Exhaust Mode:
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in exhaust mode:
- Speed 1:Â extraction rate 349 m3/h; noise level 54 dB(A) re1pW
- Speed 2: extraction rate 458 m3/h; noise level 60 dB(A) re1pWÂ
- Speed 3: extraction rate 583 m3/h; noise level 65 dB (A) re1pW
- Energy Efficiency Class: B (at a range of energy efficiency classes from A+++ to D)
- Average Energy Consumption: 70.5 kWh/year*
- Blower Efficiency Class: B*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: B*
Recirculation Mode:
- For recirculation operation Long-life Clean Air recirculation kit (accessory) needed.
- The Long-life Clean Air odour filter absorbs intense odours, such as fish, as well as pollen. The lifetime can be extended up to 4 times by refreshing the filter in the oven
- According to EN 61591 and EN/ IEC 60704-2-13 your appliance can achieve the following values in recirculation mode with Long-life Clean Air recirculation kit (available as optional accessory):
- Speed 1: extraction rate 333 m3/h; noise level 61 dB(A) re1pW
- Speed 2: extraction rate 441 m3/h; noise level 68 dB(A) re1pW
- Speed 3: extraction rate 521 m3/h; noise level 72 dB (A) re1pW
Technical Information and Sustainability:
- Consumption data:
- Power rating: 200 W
- Voltage: Nominal voltage: 220 – 240 V
- Sustainability:
- Made in Germany
- Available Long-life Clean Air odour filter with extended lifetime up to 4 times
Planning and Installation Information:
- Installation: Cupboard 60 cm
- Installation system: IDH comfort installation
- Appliance dimensions (HxWxD): 340 x 598 x 298 mm
- Built-in dimensions (HxWxD): min. 340 mm x 560 mm x min. 300 mm
- Enclosed spacers for installation in wall cupboards with maximum depth of up to 360mm.
- For installation in higher wall cupboards chimney extensions are available as optional accessories.
- Diameter pipe Ø 150 mm
- Electrical cable length 1.3 m
Appliance Frequency (Hz)
50; 60
Appliance Voltage (V)
220-240
Brand Name
Neff
Colour Name
Matt Black
Depth (mm)
298
Gross Weight
12.1
Height (mm)
60
Net Weight
7.7
Width (mm)
598
Cord Length
130
Country of Origin - Code
GERMANY
Diameter of Air Outlet
150
EAN
4242004287896
Energy Efficiency Class
B
Fluid Dynamic Efficiency
23.5
Fluid Dynamic Efficiency Class
B
Grease Filtering Efficiency
91.0
Grease Filtering Efficiency Class
B
Grease Filter Material
Washable stainless steel
Installation Type
Built-in
Lighting Efficiency
50.2
Lighting Efficiency Class
A
Max Air Flow
582
Max Niche Width
560
Max Output Air Extraction
582
Max Output Recirculating Air
521
Min Air Flow
349
Min Niche Width
560
Motor Location
Integrated motor in hood body
Niche Depth
300
Noise Level
65
No Return Air Flow Flap
No
Number of Lights
2
Number of Motors
1
Odor Filter
No
Operating Mode
Convertible
Plug Type
GB plug
Product Group
Hood
Sound Power Max Speed
65
Sound Power Min Speed
54
Type of Control
Mechanical
Type of Control Settings
Button
Type of Light
LED
Typology
Built-in/Built-under
Warranty Duration
2
Construction Type
Built-In
Grease Filter Type
aluminium
Number of Hood Speeds
3
Suggested Hierarchy
313
